DS-6v2 Double Square Metric
A Must-Have Handy Tool
With the fence square, depth gauge and marking gauge , the double fence square is a must for any woodworker. This beautifully crafted square tool can modify your layout processes for generations without wearing out or corroding. The DS-6 double square is milled to high precision. Flatness and straightness with a maximum deviation of 0.05mm are guaranteed.
Try Square
With an exceptional straightness of 0.002" (0.05mm), the SE-24 ruler (without scales) can be used to check the flatness of your workpiece.
Depth Gauge
The DS-6V2 can be used todetermine the depths of mortises, tenon stubs, rebates, blind holes and other recesses .
Marking Gauge
With this marking gauge, you can apply the necessary marking lines quickly and precisely.
Same Scale on the Same Edge
and reverse => unrestricted
The 6" imperial ruler can be read from left to right and from right to left in 1/32nd and 1/16th tel increments.
(The 300mm and 150mm Metric blades feature left-to-right and right-to-left reading 1 mm with extra 0.5mm resolution at the end.)
You can mirror the angle around its longitudinal axis and read the same scale on the opposite side. This minimizes the potential for errors in layout creation considerably.
Laser-etched Graduations
All graduations are laser- etched-they are easy to read and you should have no difficulties with clarity.
Material
The DS-6v2 Combination Squares are milled from stainless steel.
plate stock which has great rust and wear resistance, and all the surfaces of the main body and legs are complete PVD coated presenting you with the unmatched scratch
resistance and incredible hardness.
SPECIFICATIONS
DS-6v2 double stop bracket
"Some images on this page are computer-generated representations of the product and may differ from the actual product. Colors, textures, and other details may not be accurately represented in the images. Please refer to the product description and specifications for more information."
